75 Ohm SMB Plug Connector Crimp Attachment, Right Angle

75 Ohm SMB Plug Connector Crimp Attachment, Right Angle Main Specifications: General Information: Product Series: SMB Connectors   Brand: Metabee   Gender: Plug   Orientation: Right Angle   Number of Contacts: 1 Port   Contact Termination: Crimp   Mount Method: Cable Type   Mount Feature: Not Applicable   Fastening Type: Snap On   Other Feature: None   Materials and Plating: Body Material: Copper   Body Plating: Gold Plated   Insulator Material: TEFLON   Contact Material: Brass   Contact Plating: Gold Plated   Electrical Performance: Impedance: 75 Ohm   Frequency: 2 GHz   VSWR: ≤1.5 Max.   Center Contact Resistance: ≤ 6 mΩ Max   Outer Contact Resistance: ≤ 1.5 mΩ Max   Insulation Resistance: ≥ 10³ MΩ (Megohms MIN.)   Mechanical Performance: Coupling: Snap On   Contact Retention: 4 lbs MIN   Durability: ≥ 500 Times   Environmental Performance: Temperature Range:  -65°C to 155°C   Vibration: MIL-STD-202 Meth.204   Corrosion resistance: MIL-STD-202 Meth. 101   SMB Connector Interface Dimensions: Applications of this 75 Ohm SMB Plug Connector: SMB connectors are versatile RF connectors used in various industries due to their compact size and reliable performance at high frequencies. Here are some vital applications: Data; GPS System; Communications; Telecommunications; Medical; Communication; Aerospace and Defense. Download the RF Connectors PDF Catalog: Metabee's RF Coaxial Connectors Catalog (PDF, 3.7 MB) Learn more about our RF Coaxial connectors. Factory pricing and exceptional product quality. Get a free quote now! Metabee is a professional manufacturer from China. We can provide all kinds of RF connectors.
